Secure Elasticsearch On GCP With TCP Health Checks

by James Vasile 51 views

Securing your Elasticsearch cluster on Google Cloud Platform (GCP) is crucial, and one aspect of this is ensuring health checks don't inadvertently expose sensitive information. Currently, the example configurations for GCP instruct users to enable anonymous monitoring access for the Elastic cluster in order to get the GCP health check to work. This approach, while functional, has a significant drawback: it exposes monitoring information to anonymous users, which is undesirable from a security perspective. This article delves into a more secure alternative: utilizing TCP health checks for your Elasticsearch cluster on GCP.

The Problem with HTTP/HTTPS Health Checks on GCP

Currently, the example configurations for GCP instruct users to enable anonymous monitoring access (link to code) for the Elastic cluster in order to get the GCP health check to work. On GCP, HTTP/HTTPS health checks must return a 200 OK (source). This creates a security vulnerability because it requires exposing the Elasticsearch monitoring endpoint to the public internet or any user with access to the GCP load balancer. To comply with GCP's requirement for HTTP/HTTPS health checks, configurations often enable anonymous access to monitoring endpoints, which is a significant security concern. Exposing monitoring data to anonymous users could provide valuable insights to potential attackers, making the system more vulnerable.

To reiterate the problem: GCP's HTTP/HTTPS health checks necessitate a 200 OK response, forcing the exposure of monitoring data to anonymous users when applied to Elasticsearch. This practice jeopardizes the security posture of your Elasticsearch cluster by potentially revealing sensitive information about its status and performance. For those new to Elasticsearch, this might sound a bit technical, but the key takeaway is that you're essentially opening a window into your cluster's inner workings to anyone who knows where to look. That's not a comfortable position to be in, especially with sensitive data at stake. We need a better way, a more secure approach to let GCP know our Elasticsearch cluster is healthy without broadcasting its secrets to the world.

A Secure Solution: TCP Health Checks

Fortunately, there's a more secure way to approach health checks: TCP health checks. Instead of relying on HTTP/HTTPS responses, TCP health checks simply verify that a TCP connection can be established with the target service. This is a much lower-level check and doesn't require exposing any specific application data.

It is possible to instead, set GCP to use a TCP health check against the health check port that Elastic uses for Kubernetes health checks. By leveraging TCP health checks, we can circumvent the need to expose the monitoring endpoint publicly. TCP health checks operate at the transport layer, verifying the basic network connectivity to the Elasticsearch pods. This method significantly reduces the attack surface, as no application-level data is transmitted during the health check process. In essence, we're asking GCP to simply knock on the door (establish a TCP connection) rather than demanding a full report on the house's condition (HTTP/HTTPS response). This simple change makes a world of difference in terms of security. TCP health checks offer a streamlined approach, focusing on the essential aspect of connectivity without the baggage of exposing sensitive information.

Implementing TCP Health Checks in GKE

While the GKE documentation examples might not explicitly highlight TCP health checks, they are indeed a supported feature. You can configure TCP health checks using a HealthCheckPolicy resource in Kubernetes. Here's an example:

---
apiVersion: networking.gke.io/v1
kind: HealthCheckPolicy
metadata:
 name: es-lb-healthcheck
spec:
 default:
 config:
 tcpHealthCheck:
 port: 8080
 type: TCP
 targetRef:
 group: ''
 kind: Service
 name: elasticsearch-es-http

This configuration snippet defines a HealthCheckPolicy named es-lb-healthcheck. It specifies that GCP should perform TCP health checks on port 8080 of the service named elasticsearch-es-http. The key part here is the tcpHealthCheck section, which tells GCP to use TCP for its health probes. By directing the health check to port 8080, which is the standard health check port used by Elasticsearch in Kubernetes, we can verify the availability of the cluster without exposing monitoring endpoints.

Let's break down this YAML configuration for those less familiar:

  • apiVersion: Specifies the API version for the resource.
  • kind: Defines the type of resource, in this case, a HealthCheckPolicy.
  • metadata: Contains metadata about the resource, such as its name.
  • spec: Specifies the desired state of the resource.
  • default: Defines the default health check configuration.
  • config: Contains the health check configuration details.
  • tcpHealthCheck: Configures TCP health checks.
  • port: The port on which to perform the health check.
  • type: The type of health check, set to TCP.
  • targetRef: Specifies the service to which the health check policy applies.
  • group: The API group of the target service.
  • kind: The kind of the target service, which is Service.
  • name: The name of the target service, in this case, elasticsearch-es-http.

This configuration effectively tells GCP to use a simple TCP connection test on port 8080 to determine the health of your Elasticsearch service. It's a small change in configuration that makes a huge difference in security.

Benefits of Using TCP Health Checks

Switching to TCP health checks offers several advantages:

  • Enhanced Security: Avoids exposing sensitive monitoring information to anonymous users.
  • Simplified Configuration: Streamlines the health check setup process.
  • Improved Compliance: Aligns with security best practices by minimizing the attack surface.

By implementing TCP health checks, you significantly reduce the risk of exposing sensitive information while maintaining the necessary health monitoring for your Elasticsearch cluster. This approach aligns with the principle of least privilege, granting access only to what is strictly necessary. TCP health checks also simplify your overall configuration, as you don't need to manage anonymous access controls for monitoring endpoints. This can lead to a cleaner and more maintainable infrastructure. Furthermore, adopting TCP health checks demonstrates a commitment to security best practices, which can be crucial for compliance with industry regulations and standards.

Conclusion: Securing Elasticsearch Health Checks on GCP

Securing your Elasticsearch cluster on GCP is paramount, and choosing the right health check mechanism is a critical step. While HTTP/HTTPS health checks might seem like the default option, they can introduce security vulnerabilities by requiring the exposure of monitoring data. By leveraging TCP health checks, you can achieve a more secure and streamlined approach to monitoring your Elasticsearch cluster's health.

Switching to TCP health checks is a proactive security measure that minimizes the attack surface of your Elasticsearch deployment. It's a relatively simple change with significant security benefits. Remember, security is not a one-time fix but an ongoing process. Regularly reviewing your configurations and security practices is essential to maintaining a robust and secure Elasticsearch environment on GCP. So, next time you're setting up health checks for your Elasticsearch cluster, remember the power and simplicity of TCP. It's a small change that can make a big difference in your overall security posture. By adopting this approach, you're not just making your Elasticsearch cluster healthier; you're making it significantly more secure.

This article has walked you through the problem of exposing monitoring data through HTTP/HTTPS health checks and presented TCP health checks as a viable and more secure alternative. We've provided a configuration example and discussed the benefits of this approach. Now, it's your turn to take action and implement TCP health checks in your Elasticsearch deployments on GCP. Your data will thank you for it! By making this simple switch, you'll be taking a significant step towards securing your Elasticsearch cluster and protecting your valuable information. So go ahead, give TCP health checks a try – you won't regret it! Remember, every step you take towards better security is a step towards peace of mind. And in today's world, peace of mind is a valuable asset indeed.
